archlint: Enforcing Architecture Boundaries in CI, Deterministically

I wrote separately about why architecture decisions rot: an ADR says “the domain must not import infrastructure,” and two years later you find it importing the database in a hundred places — because nothing was watching the rule. This post is the tooling side of that problem: a small, standalone Go CLI — archlint.

architecture.json: put the rule in code

You declare the layers and their allowed dependencies in one file:

{
  "module": "github.com/acme/app",
  "layers": {
    "domain": ["internal/domain"],
    "db":     ["internal/db"],
    "http":   ["internal/http"]
  },
  "rules": {
    "domain": [],
    "db":     ["domain"],
    "http":   ["domain", "db"]
  }
}

domain may import nothing internal, db may import only domain, http may import both. Any other internal edge is a violation. A same-layer import is always allowed; [] means “may import no other layer.”

How it works

archlint check extracts every .go file’s imports with the standard library’s go/parser — no regex guessing, no compilation needed, exact. It maps each file and each import (after stripping the module path) to a layer, and reports the edge that breaks the rule, with file and line:

$ archlint check examples/sample
Scanned examples/sample against examples/sample/architecture.json — 2 layer(s).

1 boundary violation(s):
  internal/domain/bad.go:6  domain → db is not allowed  (import "github.com/acme/app/internal/db")

A violation exits 1 → the build goes red. The offending import is caught before it reaches main, not in an archaeology session two years later.

Design decisions

• Deterministic, no model. The whole point is a guardrail you can gate CI on: same diff, same verdict, no model in the loop. That’s the difference from telling an LLM to “review the architecture.”
• Zero dependencies (Go stdlib). The config is JSON for now — YAML adds a dependency, so it’s a follow-up.
• Go first. go/parser gives Go imports exactly; a sharp MVP is done well in one language. TypeScript and Python, via their own parsers, are the next step.

In CI

- run: go install github.com/muhammetsafak/archlint/cmd/archlint@latest
- run: archlint check

Or with the packaged GitHub Action:

- uses: muhammetsafak/archlint@v0.1.0

Limits — the honest list

• Go, for now. Imports are read with go/parser (exact); TS/Python via their own parsers is next.
• Import boundaries, for now. It governs the dependency graph between layers. A synchronous call where an async one was required, or a direct DB query across a domain boundary, needs correlating runtime traces — a later phase.
• JSON config (YAML is a follow-up). The deterministic design is deliberate: it has to be gate-able.

Try it

• github.com/muhammetsafak/archlint

Write your architecture.json, run archlint check — or run archlint check examples/sample to watch it catch a planted violation. If you tell me which boundary you want next (TS? Python?), I’ll queue it.
